Benchtop Autoclave/Steam Sterilizer Code:LFSS03AA
Category:Class B
  • Parameters
  • Function
  • Service
  • FAQ
Model LFSS03AA
Description Small Autoclave
Class B
Certification ISO 13485
Standard BS EN 13060:2004 + A2:2010
Frequency 50Hz
Plug 3 hole plug
Wattage 2900 VA
Sterilization temperature 105 - 134
Max working pressure 0.21-0.23MPA
Life span 5 years

Chamber dimensions(W*H*L)

19.5 X 7.8 X 30.3CM
Volume of chamber 3 L
Material of chamber Aluminum
Colors available White
Screen type Touch Screen
Screen size 4.3 Inch
Language available English, Chinese, Polish
Lock system of door Mechanic + electrical lockers
User password Yes
Output Thermo printer & SD Card
Net weight 20 kgs
Gross weight / carton 24 kgs
Product size( W*H*L) 28.6 X 24.4 X 55.5cm
Package size(W*H*L) 34.0 X 29.5 X 64.0cm



Front loding and fully Automatic

User Password


4 Preset sterilization programs

B&D / Helix / Vacuum testing program


Thermo Printer& SD Card


Water quality detecor incl.

Separated steam generator

High quality bacteria filter



Program

121℃
Universal

134℃
Universal

134℃
Universal quick

134℃
Solid

B&D / Helix

Vacuum test

Vacuum Times

3

3

3

1

3

3

Temp (℃)

121

134

134

134

134

/

Pressure(KPA)

110

210

210

210

210

-82

Hold Time(Min.)

20

4

4

4

3.5

/

Drying Time

8

6

4

2

4

/

Cycle Type

B

B

B

S







Warranty:
Two-years warranty for whole machine
Lifetime warranty for chamber
Lifetime maintenance

Standard packing list  Q'ty (PCS)
Autoclave 1
Power cable 1
Water drain pipe 2
Tray 2
Tray holder 1
Tray handle 1

Instruction manual 1




The working condition of the autoclave:
*         Relative humidity: ≤80%
*         Atmospheric pressure: >70kPa;
*         Voltage:230VAC, 50Hz, 2500VA
*         The highest working pressure:  0.21~0.23MPa
*         The highest working temperature: 134~137℃

The requirements of transportation and storage:
*          Environmental temperature range: 5~40℃
*          Relative humidity: ≤80%
*          No corroding gases

Warning:
*          Please use a 3-hole socket, and ensure the socket has been connected well with the ground. Do not put the autoclave on a place that the power are difficult to be cut off.
*          Do not use power with different voltage with which stated in this manual.
*          Do not touch the plug or socket with wet hands.
*          Do not pull, change, over-bend or twist the wires, and do not put heavy things on the wires.
*          Do not put the autoclave on an unstable table.
*          Do not block the door of autoclave, and cover the ventilation holes and radiation holes.
*          Do not put anything on the top of autoclave.
*          If you find any abnormal smell or sound during operation, please cut off the power immediately and contact your local distributor or us.



1. Application fields:

Dental Clinics, Veterinary (Pet Vet), Tattoo Shap, Nail(beauty) Salon, Laboratory,and so on.

1. Application fields:

Dental Clinics, Veterinary (Pet Vet), Tattoo Shap, Nail(beauty) Salon, Laboratory,and so on.
